Generator Spare Parts DSE3210 Controller For Generator Auto Start Control Module
Product ID : DSE3210
Product Tags :
Auto Genset Generator ControllerElectronic Auto Start Generator SetGenerator ATS ControllerGenerator Spare PartsGenerator Speed ControllerGenerator parts speed control unitIntelligent Generator Controller AutomaticRemote Monitor ATS AMF Generator controllerSmart Genset Controllerelectronic engine governor control
Product Attributes :
The DSE3210 includes a back-lit icon LCD display which clearly shows the status of the engine at all times.
The module monitors engine speed, frequency, voltage and engine run hours and also displays the warning and shutdown status.
The module includes fixed and flexible outputs as well as configurable inputs making this product ideal for a wide variety of applications. The module can either be programmed using the front panel or by using the DSE Configuration Suite PC software.
Product Description
|
GENERATOR CONTROL MODULE MANUAL START CONTROLLER DSE3210 |
|||
| DC SUPPLY | GENERATOR | ||
| CONTINUOUS VOLTAGE RATING | 8 V to 35 V Continuous | VOLTAGE RANGE | 15 V - 333 V AC (L-N) |
| CRANKING DROPOUTS | Able to survive 0 V for 50 mS | FREQUENCY RANGE | 3.5 Hz to 75 Hz |
| CHARGE FAIL/ EXCITATION | 8 V to 35 V fixed power source 2.5 W | MAGNETIC PICK UP | |
| NOMINAL STANDBY CURRENT | 35 mA at 12 V, 30 mA at 24 V | VOLTAGE RANGE | +/- 0.5 V to 70 V |
| MAXIMUM OPERATING CURRENT | 55 mA at 12 V, 60 mA at 24 V | FREQUENCY RANGE | 10,000 Hz (max) |
| OUTPUTS | DIMENSIONS | ||
| OUTPUT A (FUEL) | 2 A DC at supply voltage | OVERALL | 98 mm x 79 mm x 40 mm |
| OUTPUT B (START) | 2 A DC at supply voltage | PANEL CUT-OUT | 80 mm x 68 mm |
| AUXILIARY OUTPUTS C,D | 2 A DC at supply voltage | MAXIMUM PANEL THICKNESS | 8 mm |
