DSE6110 Generator Controller Auto Start Diesel Genset Control Pannel
Generator Engine Control Unit Start Control Panel DSE6110 can completely replace with it. It has the function of auto mains (utility) failure control modules monitor incoming mains (utility) supplies and instruct gen-sets to start when mains (utility) power is not available. All modules include a range of intelligent control, monitoring and protection features for standard and electronic engine gen-set applications.
Item Type: Generator Controller Module
Model: DSE6110
Working Power Supply: 8V-35V DC Voltage
Maximum Working Current: 100mA at 12V, 105mA at 24V
Maximum Standby Current: 60mA at 12V, 55mA at 24V
Maximum Sleep Current: 40mA at 12V, 35mA at 24V
Charging Failure / Excitation Range: 0V-35V
Frequency Range: 3.5Hz-75Hz
Product Size: Approx. 216 x 158 x 43mm / 8.5 x 6.2 x 1.7in
Hole Size: Approx. 184 x 137mm / 7.2 x 5.4in
Storage Temperature: -40℃~+85℃
Working Temperature: -30℃-+70℃
